Defender MINI C MK2 | LEFT | BLACK - Cable protector 3 channels | black | 45° curve left | medium
€159.56 *
Availability:
Near-term available
Delivery time: approx. 1 week
Delivery time: approx. 1 week
Delivery time: approx. 1 week
Item number: 500131625
EAN: 4069724027874
MPN: 85210L2BLK
Cable protector 3 channels | black | 45° curve left | medium load | height 5cm 45° bend LEFT... more
All information about the product:
"Defender MINI C MK2 | LEFT | BLACK - Cable protector 3 channels | black | 45° curve left | medium"
Cable protector 3 channels | black | 45° curve left | medium load | height 5cm3 small cable ducts - Lightweight and robust
Cable ducts
Environmental
Dimensions & weight
- 45° bend LEFT suitable for all products from the MINI series
- Compact, non-slip cable protector made of black, recyclable polyurethane
- Black polyurethane lid with high warning effect and secure locking mechanism
- Patented self-cleaning lid hinge
- 3 channels: 1 channel 35 x 35 mm, 2 channels 35 x 30 mm
- Load capacity approx. 2 tonnes / 20 x 20 cm
- Fire protection class E in accordance with DIN EN 13501-1 (B-s1 applied for)
- Resistant to oil, acid, petrol and short-term contact with solvents
- Reliable cable and personal protection for indoor and outdoor use
- Not suitable for road traffic
- TÜV Süd certified
The Defender® MINI Cable protector is available with a black or yellow cover and is suitable for both indoor and outdoor use. The flat, compact 3-channel Cable protector with integrated connecting pins and non-slip underside offers optimum grip on a wide variety of floors. Separately available end pieces (male/female) ensure safe, organised cable entry and exit. Defender MINI Cable protectors can withstand a load of 2 tonnes on an area of 20 x 20 cm and allow light vehicles, trolleys and pedestrians to cross. Areas of application include carnival events, trade fairs, exhibitions, shopping centres and warehouses as well as stages, studios and broadcasting stations. Not suitable for road traffic.
Technical data:General| Material: | TPU (Thermoplastic polyurethane) |
| Surface structure: | Ribbed |
| Colour: | Black |
| Lid colour: | Black |
| Maximum load (on 20 x 20 cm): | 2 t |
| Chemical resistance: | Petrol, Solvents (short-term contact), Oil |
| Hardness range (±4 Shore A): | 88 Shore A |
| Shape: | Round |
| Quantity: | 3 |
| Cable ducts size (W x H): | 35 mm x 30 mm - 35 mm x 35 mm |
| Duct length (effective length): | 1,005 mm |
| Fire protection class per DIN 4102-1: | B2 |
| Inflammability (UL 94): | V-2, HB |
| Ambient temperature: | -30 - 60 °C |
| Curve/Bend: | 45 ° |
| Length: | 0.33 m |
| Width: | 0.3 m |
| Height: | 5 cm |
| Weight: | 1.25 kg |
Further links
- Do you have any questions concerning this product?
- Further products by Defender
-
Information about the manufacturerObligation to provide information on product safety (GPSR)Manufacturer:Adam Hall GmbH
Adam-Hall-Str. 1
DE-61267 Neu-Anspach
[email protected] -
Safety instructions and warningsSafety instructions and warnings (GPSR)Specific safety instructions that apply to the product can be found in the operating instructions for the product.
