6-Channel Mixing Console with DFX 6-channel mixer with 16 digital effects 2 microphone... more

Back to the overview

All information about the product:

"LD Systems VIBZ 6 D - 6-Channel Mixing Console with DFX"

6-Channel Mixing Console with DFX

6-channel mixer with 16 digital effects

2 microphone channels with 3-band EQ

2 mono-compatible stereo line channels with 2-band EQ

Master, Monitor and headphone outputs

Securely fastening external power supply

The VIBZ 6 is a compact 6-channel mixer which is perfectly suited to entertainers, small bands, home recording and installations. It features two balanced microphone inputs with high quality preamps, phantom power and 3-band EQ with +/-15 dB adjustment scope, two stereo line inputs with 2-band EQ, which are mono-compatible, and an effects loop.

The master section of the VIBZ 6 is equipped with adjustable monitor outputs, a headphone jack and 16 digital effects presets, which are foot-switchable. The mixer also has inputs and outputs for recording and playback devices, is extremely easy to use and offers a warm differentiated sound. The external power supply can be screwed on tightly.

A foot switch for the effects section and an adapter for mounting the VIBZ 6 on microphone stands are available as accessories.

Technical data:

Product type:	Mixers
Type:	Live
Channels:	6

Mono Channels:

Mono Mic and Line Input Channels:	2
Mono Mic input connectors:	6.3 mm TRS
Mono Mic input connectors:	XLR
Mono Mic Input Type:	Electronically balanced
Mono Mic Input Frequency Range:	10 Hz
Amplification Range mono Mic Input:	0 - 50 dB
Mono Mic Input Input THD-N:	0.0058%
Mono Mic Input Impedance:	4k Ohm(s)
Mono Line Input Type:	Electronically balanced
Mono Line Input Frequency Range:	10 Hz
Amplification Range mono Line Input:	0 - 50 dB
Mono Line Input Input THD-N:	0.0045 %
Mono Line Input Impedance:	21k Ohm(s)
Mono Line Input S/N Ratio:	116 dB
Mono Channel Equalizer High:	+/- 15 dB @ 12000 Hz
Mono Channel Equalizer Low:	+/- 15 dB @ 80 Hz
Controls Mono Mic and Line Input Channels:	3-band EQ (High, Mid, Low)
Controls Mono Mic and Line Input Channels:	AUX (DFX) Post
Controls Mono Mic and Line Input Channels:	Channel Volume
Controls Mono Mic and Line Input Channels:	Gain
Controls Mono Mic and Line Input Channels:	pan
Phantom power:	48 V DC switchable

Stereo Channels:

Stereo Line Input Channels:	2
Stereo Line Input Connectors:	6.3 mm TS
Stereo Line Input Type:	Unbalanced
Stereo Line Input Frequency Range:	10 - 54000 Hz
Stereo Line Input Input THD-N:	0.0045 %
Stereo Line Input Impedance:	3,7k Ohm(s)
Stereo Line Input S/N Ratio:	116 dB
Stereo channel equalizer treble:	+/- 15 dB @ 12000 Hz
Stereo channel equalizer bass:	+/- 15 dB @ 80 Hz
Controls Stereo Line Input Channels:	2-band EQ (High,Low)
Controls Stereo Line Input Channels:	AUX (DFX) Post
Controls Stereo Line Input Channels:	Balance
Controls Stereo Line Input Channels:	Channel Volume

Main Section:

AUX / Effects Send Channels:	1
AUX / Effects Send Connectors:	6.3 mm stereo jack unbalanced
Stereo AUX Return Channels:	1 x stereo
Stereo AUX Return Connectors:	2 x 6.3 mm TRS
Stereo Tape Out Channel:	1 x stereo
Stereo Tape Out Connectors:	2 x RCA (Cinch)
Stereo Tape In Channel:	1 x stereo
Stereo Tape In Connenctors:	2 x RCA (Cinch)
Unbalanced stereo Main Outputs:	1
Unbalanced stereo Main Output Connections:	6.3 mm TRS
Unbalanced Stereo Main Out Impedance:	120 Ohm(s)
Max. Unbalanced Stereo Main Out Level:	+20 dBu
Stereo Control Room Out:	1
Stereo Control Room Out Connectors:	6.3 mm stereo jack unbalanced
Headphones ouput:	1
Headphones outputs:	6.3 mm TRS
Digital Effects Processor:	Yes, 24-bit AD/DA Resolution
Number of Presets:	16
Footswitch Connector DFX Mute:	6.3 mm TRS
Main section controls:	2-track Assignment (Main, Contr. Room)
Main section controls:	2-track In Volume
Main section controls:	DFX Mute Schalter
Main section controls:	DFX Presets
Main section controls:	DFX To Main Volume
Main section controls:	Master Volume
Main section controls:	Phantom Power
Main section controls:	Phones / Control Room Volume
Main section controls:	Stereo Return Volume
Indicators:	4-segment Level Meter
Indicators:	Channel Peak
Indicators:	DFX Peak / Mute
Indicators:	Phantom Power
Indicators:	Power
Operating voltage:	18V DC - 1 A, External PSU
Operating voltage:	230 V
Width:	209 mm
Height:	68 mm
Depth:	260 mm
Weight:	1,45 kg
