EUROLITE LED Mini PFE-12 CW

€59.90 *

incl. tax, plus shipping costs

Availability:

Delivery time: 3-5 days

Delivery time: 3-5 days

Item number: 120038020

EAN: 4026397742114

MPN: 40001762

Fanless spotlight with 12 W COB LED, adjustable light beam shape, color rendering index (CRI)... more

All information about the product:

"EUROLITE LED Mini PFE-12 CW"

Fanless spotlight with 12 W COB LED, adjustable light beam shape, color rendering index (CRI) >90

4 shutter blades
1 powerful LED COB (chip-on-board)
Focus manual
Spot effect
The device is cooled by passive convection cooling
Easy installation
With a beam angle of 28°
Very high color rendering index (CRI)
With mounting bracket
Various versions available
For application areas such as: Trade fair and shop fitting; installation; restaurants, bars and hotels; video and photography
Very quiet working noise
Application possibility: Standing; suspended

knurled screw

Package contents

Power supply:	230 V AC, 50 Hz
Power consumption:	12 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Fixed power supply cord with safety plug
Cable construction:	3 x 0,75 mm² H05VV-F
LED type:	1 x COB (chip-on-board)
Equipment:	Focus manual
Cooling:	Passive convection cooling
Setup:	Easy installation
Beam angle:	28°
Beam angle (1/2 peak):	28°
Color temperature:	5800K
Color rendering index (CRI):	91 Ra
Illuminance in Lux (lx):	1m: 2103 lx, 3m: 231 lx, 6m: 91 lx
Luminous flux:	1080 lm
Housing color:	Black matte
Attachment system:	Mounting bracket
Material:	Aluminum casting
Dimensions:	Length: 19 cm Width: 8,5 cm Height: 12,5 cm
Weight:	0,50 kg
Noise classification:	Class 1 (very slight noise, suitable for noise-sensitive environments)
Energy efficiency class (A - G):	F
Mounting bracket
Diameter mounting holes:	1 x Ø10mm
Material:	Metal, 1 mm
Knurled screw
Thread:	M4 thread x 16 mm
